DIN 42530 Bushing Metal Parts and gaskets as spare parts EN 50386 Bushings Tin plated bushings L100x100 4 hole 1000A Special flag

Transformer Bushing Flags Acc. to DIN 43675

Transformer Flag DIN 43675

Brass flags before machining


Mexican, USA, Brazilian type bushing flags

Forged copper special flag

And Special Custom Flags and Terminal Connectors For
DIN 42530, DIN 42531 , DIN 42532 , DIN 42533 , DIN 42534 , DIN 42539

We can supply you as spare parts acc.to your drawings too, for repair and maintenance service;
Transformer Bushing's Flags, ( Brass or Copper )

DP 250 DIN 43675 Vertical flag for 250A - M12x1,75 DP 630 DIN 43675 Vertical flag for 630A - M20x1,75 EP 1000 DIN 43675 Vertical flag for 1000A - M30x2 FP 2000 DIN 43675 Vertical flag for 2000A - M42x3 FP 3150 DIN 43675 Vertical flag for 3150A - M48x3 (Copper or Brass) FP 4500 DIN 43675 Vertical flag for 4500A - M55x3 (Copper or Brass) FP 6300 DIN 43675 Vertical Double flag for 6300A - Ø71 (Copper or Brass) FP M30 Nema for 2000A - M30x2 FP M42 Nema for 2000A - M42x2 FP M48 Nema for 3150A - M48x2 UNEL 1000 for 1000A - M30x2 UNEL 2000 for 2000A - M42x3 UNEL 3150 for 3150A - M48x3


Machinig of connection area		Copper 6300A double flags

Special Design of Flags can be produced for you, silver plated or tin plated contact surfaces possible,


DR 250 DIN 43675 Horizantal flag for 250A - M12x1,75 DR 630 DIN 43675 Horizantal flag for 630A - M20x1,75 ER 1000 DIN 43675 Horizantal flag for 1000A - M30x2 FR 2000 DIN 43675 Horizantal flag for 2000A - M42x3 FR 3150 DIN 43675 Horizantal flag for 3150A - M48x3 Form AP-EL Flag AF-06 type 630A flag 10-086 type 1000A flag 20-072 type 2000A flag 31-073 type 3150A flag FP6000A M64x3 180x180mm flag


from Materials: Brass (CuZn40Pb2) or Electrolytic copper possible, Forging or Casting methods
